Panasonic Lumix S5 Mirrorless Camera With 20-60mm Lens - DCS5KK
$3,399.99 CAD
Literature
You may also like
Moving Images Forward
LUMIX S5 provides exceptional image quality for photo and video across the sensitivity range within an ergonomic body designed for the quality conscious content creator.
Features
Hybrid Compact Body
This hybrid mirrorless camera features a full-frame image sensor, 10-bit C4K/4K 60p/50p recording, 14+ stops of V-Log, and more — all in an incredibly compact, lightweight body.*
24.2 MP CMOS Sensor with Dual Native ISO Technology
The 24.2 MP CMOS Sensor delivers high sensitivity and top image quality in both still photos and videos. Dual Native ISO technology* further enhances video performance. * Dual Native ISO operates automatically.
Various Recording Modes
Responding to a wide range of needs, recording modes include 4K 60p* 4:2:0 10-bit and 4K 30p 4:2:2 10-bit — plus 4K 8-bit with no limitation of video recording time. * In APS-C or PIXEL/PIXEL settings.
In the 10-bit setting, 4:2:2 10-bit HDMI output is supported along with simultaneous external drive / SD card recording.* Also, 5.9K/4K/Anamorphic 3.5K(4:3) 12-bit RAW output has become possible with the firmware update.** * SD card recording not available during 4K 60p/50p 4:2:2 10-bit HDMI output. ** Firmware must be updated to version 2.0 or later. Use the ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.55 or higher). This does not guarantee all of the capabilities that the compatible external recorder may have.
Autofocus System Featuring AI Technology
Features high-speed (approx. 0.08 sec.*), high-precision AF, and deep learning technology for recognition of human faces, eyes, heads, and bodies, as well as animals. * 11 EV, at wide-end with S-R24105 (CIPA) in LVF120 fps setting.
96 MP High Resolution Mode with JPEG
Photos can now be saved directly in the JPEG format for finely detailed, 96-megapixel-equivalent images characteristic of LUMIX. * 11EV, at wide-end with S-R24105 (CIPA) in LVF120 fps setting.
6.5-stop Dual I.S. 2
5-axis Dual I.S. 2 (Image Stabilizer) combines control of the Body I.S. and Lens O.I.S. to offer 6.5 stops’ worth of correction.* * 5-axis Dual I.S.2 can be used with the lens S-R24105, S-E70200 and S-R70200 as of September 2, 2020. Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=200 mm when S-E70200 is used.
Dust and Splash-resistant
The tough body is dust- and splash-resistant* thanks to sealing and other protection for seams, buttons and other functional parts. * Splash Resistant works in conjunction with the lenses that were specifically designed to support this feature. Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.
Other Special Features
Full-frame mirrorless camera LUMIX S5 combines maneuverability with uncompromising still photo and video performance.
Other Special Features
Full-frame mirrorless camera LUMIX S5 combines maneuverability with uncompromising still photo and video performance.
| STILL IMAGE | |
|---|---|
| File size (Pixels) | 6000x4000(L) / 4272x2848(M) / 3024x2016(S) / 12000x8000(XL)* / 8496x5664(LL)* * High Resolution Mode.5184x3456(6K PHOTO) / 3504x2336(4K PHOTO) / 5984x4000(HLG PHOTO, Full-Res.) / 3232x2160(HLG PHOTO, 4K-Res.) |
| Recording file format | JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072) |
| Latitude | |
| LATITUDE | 14+ stops (V-Log) |
| Image Sensor | |
| Dust reduction system | Image sensor shift type |
| Aspect ratio / Color filter | 3:2 / Primary color filter |
| Camera effective pixels / Total pixels | 24.20 megapixels / 25.28 megapixels |
| Type | 35 mm full-frame (35.6 mm x 23.8 mm) CMOS sensor |
| Type | |
| Lens mount | L-Mount |
| Recording media | SD Memory Card / SDHC Memory Card / SDXC Memory CardSlot 1: Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.Slot 2: Compatible with UHS-I UHS Speed Class 3 standard SDHC/SDXC Memory Cards. |
| Type | Digital Single Lens Mirrorless camera |
| MOTION PICTURE | |
| MOV** | [C4K] 4096x2160**** 29.97p, 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) *HLG is selectable.[C4K] 4096x2160**** 23.98p, 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) *HLG is selectable.[4K] 3840x2160 29.97p, 150 Mbps (4:2:2 10-bit LongGOP)* / 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) * HLG is selectable.[4K] 3840x2160 23.98p, 150 Mbps (4:2:2 10-bit LongGOP)* / 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) * HLG is selectable.[FHD] 1920x1080 59.94p, 100 Mbps (4:2:2 10-bit LongGOP)* / 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) * HLG is selectable.[FHD] 1920x1080 29.97p, 100 Mbps (4:2:2 10-bit LongGOP)* / 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) * HLG is selectable.[FHD] 1920x1080 23.98p, 100 Mbps (4:2:2 10-bit LongGOP)* / 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM) * HLG is selectable. |
| Switch NTSC / PAL | Yes (NTSC (59.94 Hz) / PAL(50.00 Hz)) |
| Recording file format | MOV: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: LPCM (2 ch 48 kHz/16-bit))MP4: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: AAC (2 ch)) |
| HDMI RAW DATA OUTPUT**** *Use the ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.55 or higher). *This does not guarantee all of the capabilities that the compatible external recorder may have. | |
| Rec quality | [5.9K] 5888x3312 29.97p, 12-bit (LPCM)[5.9K] 5888x3312 23.98p, 12-bit (LPCM) |
| MOTION PICTURE | |
| MP4** | [4K] 3840x2160 29.97p, 72 Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, AAC) * HLG is selectable.[4K] 3840x2160 23.98p, 72 Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, AAC) * HLG is selectable.[4K] 3840x2160 29.97p, 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[4K] 3840x2160 23.98p, 100 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[FHD] 1920x1080 59.94p, 28 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[FHD] 1920x1080 29.97p, 20 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[FHD] 1920x1080 23.98p, 24 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC) |
| Rear monitor | |
| Monitor size | Free-angle, 3.0-inch (7.5 cm), 3:2 aspect |
| Type | TFT LCD monitor with static touch control |
| Viewfinder | |
| Display time lag | Approx. 0.005 sec |
| Display speed | 120 fps / 60 fps |
| Eye sensor | Yes |
| Eye point / Diopter adjustment | Approx. 20 mm at infinity; -1.0 m-1 / -4.0 - +4.0 (dpt) |
| Field of view / Magnification | Approx. 100% / Approx. 0.74x with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 3:2 |
| Pixels | Approx. 2.36 million dots |
| Type | OLED Live View Finder |
| HDMI RAW DATA OUTPUT**** *Use the ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.55 or higher). *This does not guarantee all of the capabilities that the compatible external recorder may have. | |
| Audio format | LPCM (2ch 48kHz/16-bit) |
| SLOW & QUICK | |
| MP4** | [FHD] 1920x1080 59.94p, 28 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[FHD] 1920x1080 29.97p, 20 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)[FHD] 1920x1080 23.98p, 24 Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)1, 2, 5, 10, 15, 30, 60, 100, 120, 150*, 180* fps* Angle of view narrows if you select a frame rate with a number of frames 180. The AF mode switches to MF when the frame rate is set to of 150 fps or more. |
| Exposure Control | |
| Light metering mode | Multiple / Center Weighted / Spot / Highlight Weighted |
| Light metering system | 1,728-zone multi-pattern sensing system |
| Focus | |
| Others | AF-ON, AF-ON: Near Shift, AF-ON: Far Shift, Shutter AF, Half Press Release, Focus/Shutter Priority, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF-Point Scope Setting, AF+MF, MF Guide, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter, Focus Switching for Vert/Hor, Focus Ring Lock, Show/Hide AF Mode, 1-Area AF Moving Speed, Loop Movement Focus Frame, AFC Start Point (225-Area), Lens Focus Resume, Focus Ring Control |
| Post Focus / Focus Stacking | Yes / Yes |
| AF lock | Set the Fn button in custom menu to AF lock |
| AF assist lamp | Yes |
| AF custom setting | AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction |
| AF detective range | EV -6 - 20 (F1.4, ISO100 equivalent, AFS) |
| Rear monitor | |
| Pixels | Approx. 1.84 million dots |
| Field of view | Approx. 100% |
| Focus | |
| Type | Contrast AF system |
| DFD technology | Yes |
| Focus mode | AFS (Single) / AFC (Continuous) / MF |
| AF mode | Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+* / 1-Area* / Pinpoint / Custom 1, 2, 3(Full area touch is available) (Scalable AF frame size and flexible AF position) *Human/Animal Detection AF can be set ON or OFF.**** |
| Image Stabilization System | |
| IMAGE STABILIZATION SYSTEM | Image sensor shift type (5-axis / 5.0-stop*) * Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=60mm when S-R2060 is used.]Dual I.S. (6.5-stop* Dual I.S. 2 compatible) * Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=200mm when S-E70200 is used.] |
| Exposure Control | |
| AE lock | Set the Fn button in custom menu to AE lock |
| Exposure compensation | 1/3 EV step ±5 EV (±3 EV for motion picture) |
| Dual Native ISO | [Normal]Native ISO: 100, 640 Auto: Auto / 50* / 100-51200 / 102400* / 204800* * Extended ISO[V-Log]Native ISO: 640, 4000 Auto: Auto / 320* / 640-51200 * Extended ISO[HLG]Native ISO: 400, 2500 Auto: Auto / 400-51200 / 102400* / 204800* * Extended ISO[Cinelike D2 / Cinelike V2]Native ISO: 200, 1250 Auto: Auto / 100* / 200-51200 / 102400* / 204800* * Extended ISO |
| ISO sensitivity (Standard output sensitivity) | Auto / 50* / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) * Extended ISO |
| Metering range | EV0-18 (F2.0 lens, ISO100 equivalent) |
| Exposure mode | Program AE / Aperture Priority AE / Shutter Priority AE / Manual Exposure |
| BRACKET | |
| White balance bracket | 3 images in blue/amber axis or in magenta/green axis, color temperature setting |
| Focus bracket | 1 to 999 images, focus steps can be set in 10 levels |
| Aperture bracket | 3, 5 or all positions in 1 EV step |
| AE bracket | 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst |
| Shutter | |
| Silent mode / Shutter type | Yes / Yes (Auto / Mechanical / Electronic front curtain / Electronic / Electronic+NR) |
| Remote control | Remote control by DMW-RS2 (sold separately) |
| Self timer | 10 sec, 3 images / 2 sec / 10 sec |
| Shutter speed | Still image: Bulb (Max. 30 minutes), 1/8,000 - 60Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 - 60Electronic shutter: Bulb (Max. 60 sec), 1/8,000 - 60Motion picture: 1/16,000 - 1/25Creative Video M mode / MF mode: 1/16,000 - 1/2 |
| Type | Focal-plane shutter |
| White Balance | |
| Color temperature setting | 2500-10000 K in 100 K |
| White balance adjustment | Blue/Amber bias, Magenta/Green bias |
| White balance | AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4 |
| FUNCTION BUTTON | |
| REC | Exposure Comp. / Sensitivity / White Balance / Photo Style / Metering Mode / Aspect Ratio / Picture Quality / Picture Size / HLG Photo / High Resolution Mode / 1 Shot Spot Metering / Long Exposure NR / Min. Shutter Speed / 1 Shot RAW+JPG / i.Dynamic Range / Filter Effect / One Push AE / Touch AE / Exposure Mode / AF Mode / AF Custom Setting(Photo) / AF Custom Setting(Video) / Focus Peaking / Focus Peaking Sensitivity / 1-Area AF Moving Speed / Focus Ring Lock / AE LOCK / AF LOCK / AF/AE LOCK / AF-ON / AF-ON: Near Shift / AF-ON: Far Shift / AF-Point Scope / Focus Area Set / Flash Mode / Flash Adjust. / Wireless Flash Setup / Drive Mode / 1 Shot "6K/4K PHOTO" / Bracketing / Silent Mode / Image Stabilizer / Shutter Type / Ex. Tele Conv. / Live View Composite / Post-Focus / Motion Pic. Rec File Format / Motion Pic. Rec Quality / Slow & Quick Setting / Time Code Display / Sound Rec Level Disp. / Sound Rec Level Adj. / Sound Rec Level Limiter / Special Mic. Directivity Adjust / Image Stabilizer / E-Stabilization (Video) / Boost I.S. (Video) / Image Area of Video / Live Cropping / Q.MENU / Rec / Playback Switch / Video Record / LVF/Monitor Switch / Operation Lock / Dial Operation Switch / Preview / Preview Aperture Effect / Constant Preview / Level Gauge / Histogram / Luminance Spot Meter / Frame Marker / Photo Grid Line / Live View Boost / Monochrome Live View / Night Mode / LVF/Monitor Disp. Style / Photo/Video Preview / Zebra Pattern / LUT View Assist (Monitor) / LUT View Assist (HDMI) / LUT Select / HLG View Assist(Monitor) / HLG View Assist (HDMI) / Sheer Overlay / I.S. Status Scope / WFM/Vector Scope**** / Anamorphic Desqueeze Display / Focus Ring Control/ Zoom Control / Destination Card Slot / Wi-Fi / No Setting / Restore to Default |
| MOTION PICTURE FUNCTION | |
| Vertical Position Information* | ON / Off *Firmware must be updated to version 2.2 or later. |
| FILTER | |
| FILTER | Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine** For photos only. |
| PHOTO STYLE | |
| Picture adjustment | Contrast / Highlight / Shadow / Saturation / Color Tone / Hue / Filter Effect / Grain Effect / Color Noise**** / Sharpness / Noise Reduction / ISO / WB*Adjustable settings vary depending on the Photo Style mode. |
| Photo Style | Standard / Vivid / Natural / L. Classic Neo**** / Flat / Landscape / Portrait / Monochrome / L. Monochrome / L. Monochrome D / L. Monochrome S**** / Cinelike D2 / Cinelike V2 / Like709 / V-Log / Standard (HLG) / Monochrome (HLG) / Like2100 (HLG) / My Photo Style 1-10 |
| EXTRA TELE CONVERSION | |
| EXTRA TELE CONVERSION | 2.0x (EX S) (When using full-frame lenses), 1.9x (EX S) (When using APS-C / Super 35 mm lenses), 1.4x (EX M) * Only for still image recording. |
| Flash | |
| Wireless control | Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1 ch/2 ch/3 ch/4 ch |
| Synchronization speed | Less than 1/250 second * The guide number decreases at 1/250 second. Only when set to M mode or S mode. |
| Flash output adjustment | 1/3 EV step ±3 EV |
| Flash synchronization | 1st Curtain Sync, 2nd Curtain Sync. |
| Flash mode | Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off * For iA only. |
| Flash type | TTL External Flash (sold separately) |
| 6K PHOTO** / 4K PHOTO** | |
| Exif information | Yes (Each JPEG image cropped out of the 6K/4K burst file complies with EXIF.) |
| Burst speed | 6K PHOTO: 30 frames/sec4K PHOTO: 60 frames/sec, 30 frames/sec |
| BURST SHOOTING | |
| Number of recordable images | RAW / RAW+JPEG: More than 24 imagesJPEG: More than 999 images (When using a card with SD Speed Class with "UHS-II UHS Speed Class 3 (U3)" inserted into card slot 1.)* When recording is performed under the test conditions specified by Panasonic. |
| Burst speed | AFS/MF: H: 7 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)AFC: H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Interface | |
| Microphone | Stereo, Wind Noise Canceller: OFF / Low* / Standard / High * When attaching DMW-MS2 (sold separately). |
| Headphone output | φ3.5mm |
| External microphone / external audio device input | φ3.5 mm for external microphone / external audio deviceMIC (Plug-in Power) / MIC / LINE is selectable.Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (sold separately). |
| Remote input | φ2.5 mm |
| Playback | microHDMI TypeD / VIERA Link, Audio: StereoNTSC (59.94 Hz): Auto C4K/60p**** / 4K/60p / 4K/30p / 1080p / 1080i / 720p / 480pPAL (50.00 Hz): Auto C4K/50p**** /4K/50p / 4K/25p / 1080p / 1080i / 720p / 576p |
| HDMI*** | When a mode other than [C4K/60p]****/[C4K/50p]****/[4K/60p]/[4K/50p] is selected for [Picture Quality]:4:2:2 10bit, 4:2:2 8bit, 4:2:0 8bitWhen [C4K/60p]****/[C4K/50p]****/[4K/60p]/[4K/50p] mode is selected in [Rec Quality]:4:2:2 10bit*, 4:2:0 8bit * When 4:2:2 10bit mode is selected, it is not possible to record motion picture or still picture on the memory card in the camera unit.Info Display: ON / OFF (selectable)HLG View Assist (HDMI): AUTO / MODE1 / MODE2 / OFF (selectable) |
| USB | SuperSpeed USB 3.1 Gen1 Type-C |
| PictBridge compatible | |
| OSD LANGUAGE | |
| OSD LANGUAGE | Japanese, English, German, French, Italian, Spanish, Portuguese, Chinese (Traditional) |
| LEVEL GAUGE | |
| LEVEL GAUGE | Yes |
| FUNCTION BUTTON | |
| PLAY | Magnify from AF Point / LUT View Assist (Monitor) / HLG View Assist (Monitor) / Anamorphic Desqueeze Display / RAW Processing / 6K/4K PHOTO Bulk Saving / Delete Single / Protect / Rating 1, 2, 3, 4, 5 / Copy / Rec/Playback Switch / LVF/Monitor Switch / Video Record / Night Mode / Card Slot Change / Wi-Fi / Send Image (Smartphone) / LUT View Assist (HDMI) / HLG View Assist (HDMI) / 6K/4K Photo Play / No Setting / Off (Disable Press and Hold) / Restore to Default |
| Standard accessories | |
| Standard accessories | DC-S5K KitBody Cap, Hot Shoe Cover, Cover for the Battery Grip Connector, Shoulder Strap, Battery Pack, Battery Charger, AC Adaptor, USB Connection Cable (A-C), Lens Cap, Lens Hood, Lens Rear Cap・ The DC-S5 Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet. |
| Software | LUMIX Tether・ This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording, and save remotely recorded images to the PC. Check the site below to download and install the software.http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac) |
| OPERATING ENVIRONMENT | |
| Operating humidity | 10%RH to 80％RH |
| Operating temperature | 0 oC to 40 oC (32 oF to 104 oF) |
| Dimensions / Weight | |
| Weight | Approx. 714g / 1.58 lb (SD Memory Card x 1, Battery, Body)Approx. 630g / 1.39 lb (Body only) |
| Dimensions (W x H x D) | Approx. 132.6 x 97.1 x 81.9 mm / 5.22 x 3.82 x 3.22 inch (excluding protrusions) |
| POWER | |
| Battery grip | DMW-BGS5 (sold separately) |
| Actual recordable time (Motion picture)** | MP4 [4K/60p]: Approx. 55 min (APS-C, Pixel by Pixel) (LVF), 55 min (APS-C, Pixel by Pixel) (rear monitor) * When using S-R2060. When the battery is fully charged.MOV [4K/60p/4:2:0 10-bit/LongGOP]: Approx. 50 min (APS-C, Pixel by Pixel) (LVF), 55 min (APS-C, Pixel by Pixel) (rear monitor) * When using S-R2060. When the battery is fully charged. |
| Continuous recordable time (Motion picture)** | MP4 [4K/60p]: Approx. 110 min (APS-C, Pixel by Pixel) (LVF), 110 min (APS-C, Pixel by Pixel) (rear monitor) * When using S-R2060. When the battery is fully charged.MOV [4K/60p/4:2:0 10-bit/LongGOP]: Approx. 100 min (APS-C, Pixel by Pixel) (LVF), 110 min (APS-C, Pixel by Pixel) (rear monitor) * When using S-R2060. When the battery is fully charged. |
| Battery life (CIPA standard) | Approx. 440 images (rear monitor), 470 images (LVF), 1,500 images (Power Save LVF mode*) with S-R2060* Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec. |
| Battery | Li-ion Battery Pack (7.2V, 2200mAh, 16Wh) (bundled)USB power supply, USB power charging |
| DUST AND SPLASH RESISTANT | |
| DUST AND SPLASH RESISTANT* | Yes.* Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water. |
| WIRELESS | |
| Bluetooth | Bluetooth® v4.2 (Bluetooth Low Energy (BLE)) |
| Wi-Fi | 2.4GHz (STA/AP) (IEEE802.11b/g/n)5GHz (STA) (IEEE 802.11a/n/ac) * 5GHz Wi-Fi is not available in some countries.1-11, 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 ch |
| Interface | |
| XLR microphone | Yes with DMW-XLR1 (sold separately) |
| Speaker | Monaural |
| SD card slot | SD Memory Card, SDHC Memory Card, SDXC Memory CardSlot 1: Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.Slot 2: Compatible with UHS-I UHS Speed Class 3 standard SDHC/SDXC Memory Cards. |
| HDMI RAW DATA OUTPUT | |
| Compatible external devices | ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.55 or higher)* *Firmware must be updated to version 2.0 or later.Blackmagic Video Assist 5" 12G HDR, Blackmagic Video Assist 7" 12G HDR (version 3.43 or higher)* *Firmware must be updated to version 2.3.*This does not guarantee all of the capabilities that the compatible external recorder may have. |
| General | |
| Standard Accessories | Lens cap, Lens rear cap, Lens hood |
| Weight | Approx. 350 g / 12.35 oz (excluding lens cap, lens rear cap and lens hood) |
| Overall Length | Approx. 87.2 mm / 3.43 inch (from the tip of the lens to the base side of the lens mount) |
| Filter Size | φ67 mm |
| Max. Diameter | φ77.4 mm / 3.05 inch |
| INTERCHANGEABLE LENS | |
| Recommended Operating Temperature | -10 oC to 40 oC (14 oF to 104 oF) |
| Dust and Splash Resistant | Yes* |
| Diagonal Angle of View | 94°(Wide) - 40°(Tele) |
| Maximum Magnification | 0.43x |
| Closest Focusing Distance | 0.15 m/0.49 ft (at focal length 20-26 mm) / 0.4 m/1.31 ft (at focal length 60 mm) |
| Minimum Aperture | F22 |
| Maximum Aperture | F3.5 (Wide) - F5.6 (Tele) |
| Aperture Type | 9 diaphragm blades / Circular aperture diaphragm |
| Focal Length | f=20-60 mm |
| Optical Image Stabilizer | No |
| Mount | L-Mount |
| Lens Construction | 11 elements in 9 groups (2 aspherical lenses, 3 ED lenses, 1 UHR lens) |
| NAME | LUMIX S 20-60 mm F3.5-5.6 |
